CAR PRO X Fire Blanket (Reusable)

ID：Car Pro X

Reusable fire blanket, enables to contain the flames, smoke and toxic fumes in a car fire in seconds. The most efficient way to isolate and control car fires, even in electric vehicles. Suitable for professional firefighters and other organizations that may have to deal with multiple fires. Blocks and isolate fire in electric vehicles. Obtained NFPA 701 certification, EN 13501-1: Reaction to fire classification A1.

Features Video

Bridgehill Car Pro X
(Professional)

Product information

Size/Weight： ±6 x 8 m (48㎡) ±28 ㎏

Core material： 340 g/㎡ graphite

Coating： 160 g/㎡ silicone polymer (flames may occur during first time use)

*In fires with high levels of conduction heat, flames may appear from the coating of the fire blanket. This will not alter the performance of the fire blanket.

Edge of blanket：Eyelets every meter for when using the fire blanket as a fire sail.

Car sizes： Handles normal size vehicles up to SUVs such as Land Rovers, XC90 etc.

Main usage： ◇ As fire blanket ◇ As fire sail– Put vertically on the object to stop the spread of fire

Smartbag： Airtight bag. Smartbag care and maintenance: use silicon grease on the zipper to keep the bag airtight

Technical specification

Core Fabric			Unit	Tolerance
Yarn	Warp Weft	396 396	TEX TEX	±5 ±5
Yarn count	Warp Weft	4.5 4.0	Ends/cm Ends/cm	±5 ±5
Tensile strength (typical)	Warp Weft	3000 3600	N/50mm N/50mm	≧ ≧
Area weight	–	340	G/㎡	±10%
Thickness	–	0.32	Mm	±5%
Weave pattern	–			4H satin
Service temperature on core fabric	Short term ±2500℃ Long term ±1500℃

*The service temperatures are based on conditions where no oxygen is present underneath the fire blanket.

Obtained NFPA 701 Certification

Tested at RISE Fire Research

How to use

Step 1：Place the fire blanket on the ground. Center it in front of or behind the car and roll it out.

Step 2：Two people should grab each their handle and safely pull the fire blanket over the car in one continuous movement.

Step 3：Make sure the fire blanket is tight all the way to the ground and leave the fire blanket. Wait for firefighters to assess the situation further.

ALWAYS CALL THE FIRE DEPARTMENT!

Always fold the fire blanket to create two layers when using it on open lithium batteries. For proactive use on a burning building, staple the fire blanket to a wooden wall, as the last wall to fall.

Bridgehill Car Fire Blanket Pro X

Bridgehill Car Fire Blanket - how to use short version
