CAR STANDARD Fire Blanket (Single use)
ID：Car Standard-
Bridgehill Car Standard
(Single Use)
Product information
Size/Weight： Standard：±6 x 8 m ±28 ㎏
Size/Weight： Standard XL：±7 x 10 m ±42 ㎏
Core material： 380 g/㎡ pyroxene
Coating： ±50 g/㎡ BridgeTech™ (flames may occur during first time use)
*In fires with high levels of conduction heat, flames may appear from the coating of the fire blanket. This will not alter the performance of the fire blanket.
Standard Car sizes： Handle cars up to normal SUVs size like Land Rover, XC90 etc.
Standard XL Car sizes： Handle larger vehicles
Main usage： ◇ Fossil fuel vehicles ◇ Electric / hybrid vehicles
Smartbag： Airtight bag. Smartbag care and maintenance: use silicon grease on the zipper to keep the bag airtight and smell free.
Technical specification
Core Fabric Unit Tolerance Yarn Warp
Weft300
165TEX
TEX±5% Yarn count Warp
Weft8.0
8.0Ends/cm
Ends/cm±5% Tensile strength (typical) Warp
Weft3200
2500N/50mm
N/50mm≧ Thickness – 0.40 Mm ±5% Weave pattern – Plain – – Service temperature on core fabric Short term ±1600℃
Long term ±800℃Bridgehill Fire Blanket Obtained Certification
NFPA 701:2019+I
EN 13501-1: Reaction to fire classification A1
EN ISO 1182 Non-combustibility test
EN ISO 1716 Determination of the gross heat of combustion
How to use
Step 1：Place the fire blanket on the ground. Center it in front of or behind the car and roll it out.
Step 2：Two people should grab each their handle and safely pull the fire blanket over the car in one continuous movement.
Step 3：Make sure the fire blanket is tight all the way to the ground and leave the fire blanket. Wait for firefighters to assess the situation further.
ALWAYS CALL THE FIRE DEPARTMENT!
-
The Bridgehill EV Fire Blanket
How to use a car fire blanket - emergency version
-
