Lithium(1)

Forklift & Pallet Truck Fire blanket

ID：Forklift / Pallet Truck Standard
The Bridgehill Forklift Fire Blanket enables you to isolate the flames, smoke, and toxic fumes in seconds – and control the fire in minutes. It works effectively on forklifts, small vehicles, and machinery, and is the only solution to also work on vehicles with lithium batteries. Ideal for warehouses, factories and other workspaces with forklift trucks, small vehicles and machinery. Obtained certifications: •EN 13501-1: Reaction to fire classification A1 •EN ISO 1716: Determination of the gross heat of combustion •EN ISO 1182: Non-combustibility test
Features Video

  • Bridgehill Forklift / Pallet Truck

    Fire Blanket

    Product information

    Size/Weight：

    Forklift Standard– ±7 x 7 m ±30 ㎏

    Pallet Truck– ±5 x 5 m ±30 ㎏

    Core material： 380g/㎡ pyroxene

    Coating： 120g/㎡ silicone polymer (flames may occur during first time use)

    *In fires with high levels of conduction heat, flames may appear from the coating of the fire blanket. This will not alter the performance of the fire blanket.

    Main usage： ◇ Fossil fuel forklifts ◇Electric forklifts (isolating the fire in the battery)

    Smartbag： Airtight bag. Smartbag care and maintenance: use silicon grease on the zipper to keep the bag airtight and smell free.

    Technical specification

    Core Fabric Unit Tolerance
    Yarn Warp
    Weft    		 300
    165    		 TEX
    TEX    		 ±5%
    Yarn count Warp
    Weft    		 8.0
    8.0    		 Ends/cm
    Ends/cm    		 ±5%
    Tensile strength (typical) Warp
    Weft    		 3200
    2500    		 N/50mm
    N/50mm    		 ≧
    Thickness – 0.40 Mm ±5%
    Weave pattern – Plain – –
    Service temperature on core fabric Short term ±1600℃
    Long term ±800℃

    How to use

    Step 1：Place the fire blanket on the ground in front or behind the forklift and roll it out.

    Step 2：Two people should grab each their handle and safely pull the fire blanket over the forklift in one continuous movement.

    Step 3：On forklifts with a tall mast, cover the cabin not the mast (the yellow arrow). Make sure the fire blanket is tight all the way to the ground and leave the fire blanket. Wait for firefighters to assess the situation further.

     ALWAYS CALL THE FIRE DEPARTMENT!

  • Forklift fire blanket - how to use
