Lithium Fire blanket

ID：Lithium

Lithium fire blanket is the simplest, safest, and most effective way to isolate lithium battery fires- such as in e-scooters, e-bikes, and open battery fires. It can immediately isolates toxic gases and smoke and protects civilians from carcinogen exposure. Obtained certifications: •EN 13501-1: Reaction to fire classification A1 •EN ISO 1716: Determination of the gross heat of combustion •EN ISO 1182: Non-combustibility test •EN 1869:2019: Fire Blankets

Features Video

Bridgehill Lithium Fire Blanket

Product information

Size/Weight： Standard– ±1.8 x 1.8 m ±8 ㎏

Size/Weight： Large– ±3 x 4 m ±27 ㎏

Core material： Pyronxene, selicium flit, and BridgeTech™coating– a seven layer solution

Main usage： Isolate fire in open lithium batteries

Smartbag： Airtight bag. Smartbag care and maintenance: use silicon grease on the zipper to keep the bag airtight and smell free.

Technical specification

Core Fabric			Unit	Tolerance
Yarn	Warp Weft	300 165	TEX TEX	±5%
Yarn count	Warp Weft	8.0 8.0	Ends/cm Ends/cm	±5%
Tensile strength (typical)	Warp Weft	3200 2500	N/50mm N/50mm	≧
Thickness	–	1.0	Cm	±5%
Weave pattern	–	Plain	–	–
Service temperature on core fabric	Short term ±1600℃ Long term ±1200℃

How to use

Step 1：Place the fire blanket on the ground.

Step 2：Gently cover the burning battery. For bigger batteries we recommend using a bigger fire blanket on top to prevent flames from coming out.

Step 3：The blanket needs to fully cover the object, and leave it to the firefighters to assess the situation.

ALWAYS CALL THE FIRE DEPARTMENT!

Use proper protection and breathing apparatus (BA) due to the release of toxic gases from the burning battery.

Bridgehill Lithium Fire Blanket and Car Pro X Fire Blanket used on Lithium-ion Battery Module-fire

Bridgehill Lithium fire blanket used on Lithium-ion Battery Module-fire
